Double Column Horizontal Band Saw GH4220A, GH4228, GH4235

Main Features:

1.   Double column structure vertical lifting high stability

2.   High efficiency, high precision save material saving energy

3.   The hydraulic pressure controls the speed of saw stepless speed regulation

4.   The camp of workpieces and hydraulic, control easily

5.   Can made 3 hydraulic tension saw blades per request

Description

MODEL NO GH4228 GH4220A GH4235
Cutting capacity 280-280×280 200-200×200 350-350×350
Blade speed 3505×27×0.9 2800×27×0.9 4115×34×1.1
Blade size 27、45、69 27、45、69 27、45、69
Motor main 2.2 1.5 3
Motor hydraulic 0.55 0.55 0.55
Coolant pump 0.04 0.04 0.04
Workpiece clamping MANUAL Hydraulic Hydraulic
Size outward 1860×900×1400 1400×900×1100 2000×1000×1300
