Portable Band Sawing Machine G5012W

Main Features:

1. 150X100mm (W x H) rectangular capacity

2. Adjustable spring tension screw regulating cutting feed rate

3. Fully-adjustable blade roller for accurate and straight cutting

4. Adjustable length stop for repetition cutting

5. 3-speed pulley drive system

6. Automatic electric cut-out switch

7. Vertical cutting table included

8. Portable – on wheels for site work

9. Cuts 0 to 45º degrees in miter vice

10. Sealed worm and pinion gear box drive





Description

Model G5012W
Motor 370W
Vertical worktable 245x245mm
Working capacity 90 degree  rectangular 100x150mm(4″x6″)
 circular 100mm(4″)
Blade size 1638×12.5×0.6mm
Blade speed 50Hz: 20,29,50,/min
60Hz: 24,36,61m/min
vice tilt 0-45degree
Packing size 1020x320x390
N.W/G.W 61/64Kg
