Hydraulic Shearing Machine HS-25

Main Features:

1. HS-25 Hydraulic Shearing Machine is specially designed to shear straight metal section bars.

2. It can also be used in cooperation with other machines.

3. With such striking features as swiftness, convenience, accuracy and quietness, the machine has been widely applied in the fields of architecture, smelting and furnishing industries, etc.

Description

Item HS-25
Nature of Working Materials Mild Steel
Round Steel less than Φ25
Specifications of Working Materials Angle Iron less than 50×50×5
Square Steel less than 20×20
Flat Steel less than 50×10
Section Bar less than 25Regular hexagon
Max. Working Pressure(KN) 100
Max. Working Distance(mm) 250
Functions of Motor Voltage 380V
Frequency 50/60HZ
Rotational Speed 1400(r/min)
Power (KW) 3
External Size(L×W×H)mm 920*600*1200
Net Weight (Kg) 300
Gross Weight (Kg) 370
