Hydraulic Bending Press HPB Series

Main Features:

1.   HP series hydraulic press are used for assembling, dismantling, alignment, calendaring, tension, bending and punching.

2.   The machine supplied oil by Italy CNK and CBZ pump.

3.   It could save 60 percent energy compared with the traditional model.

4.   The efficiency increased to 2-3times.

5.   It takes the advantages of small volume, high pressure, simple structure and light weight.

6.   Function of press braking and bending

Description

Model HPB-20 HPB-30 HPB-50 HPB-63
Capacity (KN) 200 300 500 630
Pressure (Mpa) 25 25 25 30
Travel (mm) 200+270 300+270 220+405 220+405
Table size (mm) 200×360 300×400 400×800 400×800
Packing size (mm) 1060×500×1400 1160×550×1600 1500×650×1950 1500×650×1950
Net weight (kg) 550 650 1100 1200





Model HPB-1010 HPB-150 HPB-200 HPB-300
Capacity (KN) 1000 1500 2000 3000
Pressure (Mpa) 30 30 30 30
Travel (mm) 250+405 250+405 300+405 300+405
Table size (mm) 460×980 460×980 500×1000 700×1200
Packing size (mm) 1730×730×2250 1730×730×2250 1940×950×2350 2100×950×2700
730×630×960 730×630×960 900×800×1060 1100×1200×1350
Net weight (kg) 1420 1750 2400 4200
