Name: Hydraulic Shaping Machine BY60100C,BY60125C
SKU: 1951
Availability: InStock

Hydraulic Shaping Machine BY60100C,BY60125C

Main Features:

1. The machine is suitable for various cutting plane, formed surface and is suitable for single piece and small batch production.

2.The main cutting movement and feeding movement are driven by hydraulic transmission, with stepless speed adjustment.

3.This machine has hydraulic overload insurance device, with the smooth transmission, small excess of stroke, reliable and flexible

starting and stopping.

4. This machine has a high rigidity, strong cutting force and high reversing precision, low oil temperature, small thermal deformation.

5. This machine has a stable accuracy and can adapt to the strong cutting and continuous work.

6. The machine table can realize the fast moving in vertical and horizontal directions, and the tool post has the automatic tool-relief mechanism.

7. The handles of the machine is centralized, so it is convenient for operation.

Description

Item	unit	BY60100C	BY60125C
Max. planning length	mm	1000	1250
Working speed of the ram(stepless)	m/min	3-44	3-44
The distance from the ram bottom to worktable surface	mm	80-400	80-400
Max. cutting force	N	28000	28000
Max. stroke of tool post	mm	160	160
Max. section size of the tool bar(width× height)	mm	30×45	30×45
Working size of the worktable(length× width )	mm	1000×500	1250×500
T slot width of the worktable surface	mm	22	22
Max. horizontal stroke of worktable	mm	800	800
The horizontal feeding range of worktable every counter-recoil travel of ram(stepless)	mm	0.25-5	0.25-5
Main motor power	kw	7.5	7.5
Fast moving motor of the worktable	kw	0.75	0.75
Overall dimension(L×W×H)	mm	4270×1610×1970	3615×1574×1760
Net weight (about)	kg	5000	5000
