Gap Bed Lathe Machine C0632A

Features

1.recision ground and supersonic frequency hardened bed ways

2.The spindle is supported with precision roller bearings

3.Headstock gears are made of high quality steel, ground and hardened

4.Spindle speed range 70-2000RPM

5.Sealed and easy operating feed box has various feeds and thread cutting functions

6. Coolant system

7.Apron-mounted spindle ON/OFF lever

8.Removablechip tray

Category:
Tags:

Description

ITEMS C0632A
Max. swing over bed 13″(330mm)
Max. swing in gap 183/4″(476mm)
Max. swing over slide 71/4″(185mm)
Bed width 73/8″(187mm)
Max. Length of workpiece 30″(750mm)40″(1000mm)
Spindle nose D1-4
Spindle bore 11/2″(φ38mm)
Taper of bore in spindle Morse No.5
Spindle  speed steps 8
Spindle speed scope 70～2000r/min
Inch thread 4～56T.P.I/32
Metric thread 0.4～7mm/32
Diametral thread 8～120D.P./33
Module thread 0.2～3.5MP/27
Longitudinal feed range 0.0032～0.1067in/r(0.082～2.71mm/r)
Cross feed range 0.00086～0.0367in/r(0.022～0.933mm/r)
Max. travel of tailstock quill 35/8″(95mm)
Taper hole of tailstock No.3
Electric motor 2HP(1.5KW)110v or 220v(1ph)380v(3ph)
Net weight / Gross weight(1000mm) 495/595kg
