Bed-Type Milling Machine X715
Main Features:
1. Rigid grey cast-iron construction allows heavy work load
2. Universal milling head system “Huron” can be adjusted to various angles
3. Solid flat guiding guarantees stability at heavy milling
4. Complete with swivel arm and clearly arranged control panel
5. Inductive hardened and polished guiding
6. Stepless feed adjustments in all axis
7. Reinforced saddle in robust box construction
8. Precisely polished table, ideally positioned on wide saddle
9. Column and stand in solid box construction
Description
| TECHNISCHE | X715 |
| Table size | 2100 x 500 mm |
| Spindle taper | ISO 50 |
| Spindle speed | (12) 40 – 1600 rpm |
| Travel longitudinal (x) | 1500 mm |
| Trave cross (y) | 700 mm |
| Trave vertical (z) | 700 mm |
| Distance spindle to column | 610 mm |
| Spindle head tilting range | 360° |
| Distance spindle to table | 0 – 700 mm |
| Feeding speeds | / |
| x-axis (stepless) | 20 – 1800 mm/min |
| y-axis (stepless) | 20 – 1800 mm/min |
| z-axis (stepless) | 10 – 900 mm/min |
| Rapid feed x- and y-axis | 3500 mm/min |
| Rapid feed z-axis | 1750 mm/min |
| Feeding motor power | 2,0 kW |
| Coolant motor power | 0,5 kW |
| Main motor power | 7,5 kW |
| Machine dimensions (W x D x H) | 3300 x 2380 x 2750 mm |
| Weight approx. | 7300 kg |
