Name: Drilling and Milling Machine
SKU: 1205
Availability: InStock

Drilling and Milling Machine

Main Features:

1. Uses standardized assemblies from the VH milling machine universal use as milling machines and drill press

2. Easily shiftable gear driven sures power transmission without losses

3. With V-belt spindle drive and gear spindle drive

4. Head swivels into the horizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill

5. Three axis hardened treatment, high rigidity.

6. Vertical horizontal multi-functional ,drilling ,milling, boring operation.

7. X axis mechanical feed, Y. Z axis can be added the device

8.Gear transmission milling head, stable transmission, compact structure ,easy maintenance, easy to operate

Description

Model	ZX7550W	ZX7550CW
Max. drilling diameter (mm)	50	50
Max. horizontal milling diameter (mm)	100	100
Max. vertical milling diameter (mm)	25	25
Max. boring diameter (mm)	120	120
Max. tapping diameter	M16(Vertical)	M16
Spindle Tapper	ISO30/R8	ISO30/R8
Distance. spindle to table surface (mm)	80-460	90-490
Spindle speeds range (r.p.m)	230-1825(Vertical) 80-1300(horizontal)	(Vertical)115-1750 (Horizontal)60-1350
Spindle travel	120	120
Table size (mm)	800×240	800×240
Table travel (mm)	400×230	400×230
Overall dimensions (mm)	1280×1100×2080	1280×1100×2080
Motor (Kw)	0.85/1.5(Vertical) 1.1(horizontal)	( Vertical)0.85/1.5 (horizontal)2.2
N.W/G.W (Kg)	700/880	850/1000
