Name: Drilling and Milling Machine ZAY
SKU: 1184
Availability: InStock

Drilling and Milling Machine ZAY

Main Features:

1. Quiet B section belt drive system

2. Milling head rotates 360º on column

3. Extra large 820 x 240mm ground work table with T-slots

4. Adjustable leadscrew nuts eliminating back lash on both axis

5. Fine feed hand wheel operating quill feed

6. Forward and reverse on/off switch

7. 3MTspindle with 75mm diameter quill

8. Adjustable table and drill length stops

9. Rack and pinion wind-up head

10. Rear slide-way cover and slide clamps on all axis

11. Spindle lock for quill

12. Table lock on both axis

13. Metric dial graduations @ 0.05mm for X & Y axis

14. Optional power feed fits straight on the table

Description

SPECIFICATION
Model	ZAY7020	ZAY7032	ZAY7040	ZAY7045
Drilling capacity	20mm	32mm	40mm	45mm
Face milling capacity	63mm	63mm	80mm	80mm
End milling capacity	20mm	20mm	32mm	32mm
Distance from spindle nose to table	435mm	450mm	450mm	450mm
Min. distance from spindle axis to column	181.5mm	203.5mm	203.5mm	203.5mm
Spindle travel	85mm	130mm	130mm	130mm
Spindle taper	M.T.3 or R8	M.T.3 or R8	M.T.4 or R8	M.T.4 or R8
Step of spindle speed	12	12	12	12
Range of spindle speed 50Hz	100-2200 r.p.m	80-2080 r.p.m	80-2080 r.p.m	80-2080 r.p.m
60Hz	120-2640 r.p.m	100-2500 r.p.m	100-2500 r.p.m	100-2500 r.p.m
Swivel angle of headstock (horizontally)	360°	360°	360°	360°
Table size	520×160mm	800×240mm	800×240mm	800×240mm
Forward and backward travel of table	140mm	175mm	175mm	175mm
Left and right travel of table	290mm	500mm	500mm	500mm
Motor Power	0.55KW	0.75KW	1.1KW	1.5KW
Voltage/frequency	As customer’s requirement
Net weight/gross weight	130kg/190kg	280kg/330kg	283kg/333kg	285kg/335kg
Packing size	620×750×1000mm	1020×820×1160mm	1020×820×1160mm	1020×820×1160mm
Loading amount	48pcs/20＇container	28pcs/20＇container	28pcs/20＇container	28pcs/20＇container
