Main Features:

1  Swallow tail guide ways with high accuracy.

2. Hardened and ground table surface, guideways with longer life.

3. Automatic feeds on x, y axes, motorized lifting and lowering of table on z axis

4. Head spindle swivel angle +/-45degrees;

5. With enforce lubricating on X,Y,Z-axis and guide way  with less ware out for  the machine

6. Knee part with 3 supporter for Heavy load on the worktable.

7. Table Longitudinal and cross auto-feed with interlock system to avoid the error operation.

8.Worktable can be rotary, by +-45°for more wide use of the cutting. By the rotary, with the dividing head accessory can realize spiral plane cutting .

9. Main transmission and feeding part are with gear-drive for heavy-cutting.
